Micro - computer Controlled Stepping Motor Non Woven Bag Making Machine With Fully Automatic Sealing Hand Loop And Side

Ask Lasest Price
Brand Name :	LS
Model Number :	WFB
Certification :	CE
Supply Ability :	20sets/month
Delivery Time :	Within 30 working days

Add to Cart

Product Details
Company Profile

Micro - computer Controlled Stepping Motor Non Woven Bag Making Machine With Fully Automatic Sealing Hand Loop And Side

Micro - computer Controlled Stepping Motor Non Woven Bag Making Machine With Fully Automatic Sealing Hand Loop And Side

Quick Detail:

Condition: New
Material: Non woven bag
Machine type: Bag forming machine
Bag Type: Soft Loop Handle Bag

Sealing Mode: Ultrasonic Sealing
Max. Bag Making Width:600mm

Bag Making Thickness: 20-80g
Power: 22 w
Capacity: 40-90 pcs/min
Warranty: one year
Certification: CE

Description:

1. This machine is the present domestic function is the most complete, the performance is the most stable automatic non-woven bag making machine. On the basis of the original bag making machine, add automatic bonding handle. That is real liberating manual and fully automatic production of non-woven bag. It compared with the similar machine, higher precision, less waste, faster and achieved maximum benefit for you.

2. This machine widely used in producing non-woven handle bag, flat bag, box bag, T-shirt bag, organ bag, gift bag, pillow bag, zipper bag, drawstring bag, etc. The produce different bags as long as change the way of material. It is simple operation, high efficiency and good stability. The whole machine adopts microcomputer control and material pulling by stepping motor. Automatic positioning and bonding handle. It arbitrary fixed length, accurate and stable step photoelectric tracking, automatic punching, counting, alarming and stopping when the label is lost.

Specifications:

Model	WFB-AT600
Max.Bag Making Width	600mm
Bag Making Thickness Range	20-80g
Max.Bag Making Length	700mm
Production Speed	40-90pcs/min
Total Power	22kw
Machine Weight	3.5t
Overall Demensions	1200020002100mm

1) Main motor with frequency conversion(made in Shanghai), speed can be adjusted

2) Micro-computer controlled stepping motor

3) Pneumatic shaft axis

4) EPC(edge position control) controls material running

5) Side-folding,heating with electrical temperature-controlled

6) Material half-fold, with EPC control

7) Tachometer shows as the material runs

8) Adjusted lever with air cylinder tension control

9) Ultrasonic made in Jiangsu, Japan Chip, YDN Brand

10) Photocell tracks the printing material

Application:

This machine is a kind of ideal equipment for non-woven fabric(with printing or not) shopping bag,handle loop bag,vest/T-shirt bag,pillow bag,gift bag,shoes bag,ribbon through bag etc.
Bag making and handle loop fix can be done at one time,
The advantage of our machine is reasonable structure and refined parts.
That can reduce the waste and space because of it is shorter than competitors’ machine
handle loop fix is auto fully and high accuracy, improve your efficiency and reduce the
defective percentage, adopts a unique structure, utilizing step motor for feeding material, realizing precise transferring, combining interactive interface with all complete parameters, easier and more intuitive.

Our Product Sample Show:
