2 Color Plastic Bag / Plastic Film Packing Flexographic Printing
Machine , long life
Use:
Machinery products developed in the recent years, we have many
kinds machine,
such as normal-speed 10-60m/min, Middle-speed 10-100m/min, ,
high-speed over 120m/min standards.
The main features:
1.Take it easy, accurate color, long life.
2. Use motors, variable frequency speed control, saving
electricity, small running fluctuations.
3. Off printing roll automatic stop the ink-running motor, and
up-printing roll automatic start running the ink.
4. Use special diagonal-tooth gear, accurate printing size.
5. Two sets of heating devices, including central heating and
constant temperature contro
l system for group control.
6. Low-roller special steel processing, and special process, and
plating thickness of 0.1mm
protective layer of hard chromium.
7. Alloy roll with hard oxidation, treating by dynamic balance,
static balanced.
8. With cold wind bellows, and can effectively prevent produce with
ink adhesion after printing
9. Print produce are clear and good arrangement quality.
10. Bearing: NSK, Japan Brand, Germany ASNU aluminum alloy roll
Machine process:
Unwinding unit-----auto tension controller for unwind ------EPC for
correct position ---------Flexo printing
-----------Heating and drying -------Rewinding Unit
Main Technical :
Model | YTB21000 |
Max. print material width | 10 50mm |
Printing width | 9 60mm |
Printing material | Paper: 50 ~ 35 0g/m2 |
Printing color | 6 color (6+0) |
Printing length | 7.5"~ 5 0"(190mm~1 5 00mm) |
M e ch a nical speed | 9 0m/min |
Printing speed | 1 0m- 7 0m/min ( if you need high speed machine, pls contact Linda 0086-18857728175) |
Register precision | Longitude:±0.25mm Transverse:±0.25mm |
Rewinder/Unwinder DIA | Φ 12 00mm (unwinding)
Φ 13 00mm (rewinding) |
Printing plate lifting system | Auto Hydraulic cylinder control printing roll up and down |
EPC system: | Edge Position Controller, 1 PC |
Tension system | Automatic tension control for unwinding 1 PCS |
Unwinding loading and rewinding unloading way | By air shaft , with 10 kg magnetic 2 pcs
With 1.5 kw motor compages rewinding |
Printing Pressure | M echanical adjust |
Anilxo roll | Standard metal anilxo roll (1 0 0-300PLI)
Or
High: ceramic anilox roller ( 3 00-800lpi), single doctor blade |
Master motor | 3.7Kw TAIWAN BRAND |
Drying way | Electrical heat drying |
Drying power | 24 kw |
Blower of nature wind | 0.95 Kw x 6 pcs
75W x 12 pcs |
Inking motor | Taiwan brand |
Master frequency converter | 3.7 kw |
Master power | 32 Kw |
Dimension(L×W×H) | 5.4 ×2. 4× 3.2 m |
Sample :
