    4 color High Speed CI flexo printing machine for roll to roll PE, Paper, non woven, pp

    Ask Lasest Price
    Brand Name : Lisheng
    Model Number : YTCI-41000
    Certification : CE, ISO
    Price : USD51000
    Payment Terms : Western Union, T/T, L/C
    Delivery Time : 20-30sets/ month
    • Product Details
    • Company Profile

    4 color High Speed CI flexo printing machine for roll to roll PE, Paper, non woven, pp

    Characteristics:

    1. Central impression type printing machine with better color registration. Due to the big drum, the printed material is supported by the big drum, and greatly improving color registration, especially with extensible materials.
    2. All colors printing station drived by the central drum, Less transmission errors because of less gear transmission, increase the registration precision.
    3. Adopting high-quality motor, high-quality inverter, save the electricity, reduce the run fluctuation.
    4. When the machine is stopped working, printing rolls still keep moving; when rise the printing roller ,ink motor running automatically ;when fallen the printing roller, ink motor stop running automatically.
    5. The machine is equipped with blower and heater; and the heater employed central temperature control system, automatic temperature controller, and separated heat source.
    6. The use of individual drying oven and cold wind system can effectively prevent the ink adhesion after printing.
    7. Roller adopts special steel processing, and through special treatment, greatly reduce the beating range.
    8. Printing roller uses static balance and dynamic balance processing, hard anode oxidation treatment, small resistance, beating small, achieves finally perfect printing effect.
    9. Accurate printing effect achieved by special gear transmission device.
    10. The printing machine all can choose advance configurations to achieve the high quality, the high-definition effect.

    SUITABLE MATERIAL:

    Kraft paper:40-350g/㎡ single-sided coated paper:30-350g/㎡ copy paper:15-350g/㎡ firecrackers and paper:40-350g/㎡ paper money and incense:25-350g/㎡ silicone paper:50-350g/㎡ coated paper:30-350g/㎡ dust-free paper:25-350g/㎡Release paper:40-350g/㎡ composite paper:30-350g/㎡
    woven:15-120g/㎡ Weave fabric:15-500g/㎡
    PVC:10-120g/㎡ OPP:10-120g/㎡ PE :10-120g/㎡PET: 10-120g/㎡CPP:10-120g/㎡

    Technical Specification
    ModelYTC-41000
    Material feeding width1000mm
    Max Printing Width960mm
    Colors4colors
    MaterialNon-woven fabric. Paper. Film. Aluminum foil. PVC.OPP.PE.BOPP.PE.NY.PET.CPP.
    Thickness of plate

    1.7mm 2.28mm 3.94mm

    Customized is available

    Printing length

    Standard is 400mm,

    Customized is available from 280-1000mm

    Maximum machine speed150m/min
    Printing speed120m/min
    Register precision±0.15mm
    Structure typeCentral impression(central drum)
